Overall Length	9 3/4" (248 mm)
Weight	4.6 kgs (10.1 LB)
Square Drive	3/4"
Bolt Capacity	7/8" (M24)
Avg. Air Con.	4.2 CFM (119 L/min)
Air Inlet	1/4"
Hose Size (I.D.)	3/8"
Air Pressure	90 PSI (6.2 Bar)
Torque (5 Sec.)	700 FT-LB / 949 N.m.
Max Torque (10 Sec.)	800 FT-LB / 1085 N.m.
Free Speed	4800 RPM
Vibration	5.8 m/s2
Sound Pressure Level	86 Dba

APPLICATION



FEATURES

Mechanism: Pin Clutch
Hand push reciprocating forward-reverse switch, and high-low speed regulator
Highest durable grade steel anvil
Front exhaust
Powerful, stable and continuous torque
Components with durable and heavy duty materials
Quieter operation, less vibration
Die casting housing
Kit set available：sockets &ndash 26, 27, 29, 30, 32, 35, 36, 38mm
