Overall Length	8 1/4" (210 mm)
Weight	4.3 kgs (9.5 LB)
Square Drive	3/4"
Bolt Capacity	1" (M25)
Avg. Air Con.	5.30 CFM (150 L/min)
Air Inlet	1/4"
Hose Size (I.D.)	3/8"
Air Pressure	90 PSI (6.2 Bar)
Torque (5 Sec.)	900 FT-LB / 1220 N.m.
Max Torque (10 Sec.)	1000 FT-LB / 1356 N.m.
Free Speed	6300 RPM
Vibration	5.8 m/s2
Sound Pressure Level	92 Dba

APPLICATION



FEATURES

Mechanism: Twin Hammer
Hand push reciprocating forward-reverse switch, and high-low speed regulator
Highest durable Japan&rsquos steel anvil
Front exhaust
Light weight and short length for narrow area
Excellent power-weight ratio
Components with durable and heavy duty materials
Two piece housing for easy service
Air circulation is good in housing which can make front housing cold down
Die casting housing
Kit set available：sockets &ndash 26, 27, 29, 30, 32, 35, 36, 38mm
