Overall Length	16 1/2" (420 mm)
Weight	13.6 kgs (30 LB)
Square Drive	1"
Bolt Capacity	1 1/4" (M32)
Avg. Air Con.	7.4 CFM (210 L/min)
Air Inlet	1/2"
Hose Size (I.D.)	1/2"
Air Pressure	90-115 PSI (6.2 Bar)
Torque (5 Sec.)	1000 FT-LB / 1356 N.m.
Max Torque (10 Sec.)	1300 FT-LB / 1763 N.m.
Free Speed	3500 RPM
Vibration	5.8 m/s2
Sound Pressure Level	105 Dba

APPLICATION



FEATURES

Mechanism: Two Hammer
Highest durable steel Anvil (2", 6" & 8" optional)
Front exhaust
Forward & Reverse：1 position for each side
Powerful instantaneous torque with stability
Heavy duty casting of housing
Inside or outside trigger available
Components with durable and heavy duty materials
